適用材料Applicable material
樹脂顆粒、樹脂膜粉粒品、玻璃纖維、碳纖維、母粒（色母粒）等
Resin pellet,Fluff,Glass fiber,Carbon fiber
特點Characteristics
1、微振動供料，不會對物料造成損傷
2、對纖維狀物料幾乎不會有解纖現象
3、無脈動，保證供料順利
4、全量排出時的殘量少、易清掃
?Materials are fed by minute vibration,thus are delivered damage-off.
?Fiber materials rarely untwine.
?Fddeing proceeds smoothly without any fluctuation in flow rete.
?Little residue remains after discharge,so cleaning is easy.
規格specification
|
型號 Model |
流量范圍 Flow rate range |
料斗容量 Hopper capacity |
稱量 Weigh capacity |
振動槽寬 Trough width |
產品重量 Feeder weight |
電源 Power supply |
|
HF-V-1A(-MP) |
0.5-10kg/h |
15L |
30kg |
15mm |
約59(89)kg Approx59(89)kg |
AC220V 單相0.3KVA 220V AC,1phase，0.3kVA |
|
HF-V-1B(-MP) |
5-100kg/h |
25L |
30mm |
|||
|
HF-V-2A(-MP) |
10-150kg/h |
50L |
30kg |
60mm |
約62(92)kg Approx62(92)kg |
|
|
HF-V-2B(-MP) |
20-400kg/h |
80L |
100mm |
|||
|
HF-V-3C(-MP) |
80-1000kg/h |
100L |
100kg |
150mm |
約150(200)kg Approx150(200)kg |
AC220V 單相0.4KVA 220V AC,1phase，0.4kVA |
（ ）內為控制模塊KB-2500G一體式的數據。 Specifications in parenthesis( )are for modeis unitized with control module KB-25000G
